Product DescriptionCompany Info.
The instrument is mainly used to determine the penetration of viscous road petroleum asphalt, polymer modified asphalt, residue after distillation of liquid petroleum asphalt or evaporation of emulsified asphalt, petroleum wax, grease, etc., calculated by 0.1mm. The standard test conditions are temperature 25℃, load 100g, penetration time 5 s.
LZRD-7 high and low temperature asphalt penetration tester Product characteristics:
(1) The instrument adopts 7-inch LCD touch screen and CPU microcontroller control, which improves the integration degree of the instrument and makes the operation simpler and clearer; realizes the automation, digitalization and computerization of the test process;
(2) The instrument adopts a new grating displacement sensor, which improves the accuracy of penetration measured by the instrument.
(3) The instrument design newly adds a temperature control device system with refrigeration, which can control the water temperature of the equipment at about 25℃ 0.03℃, which can effectively increase the measurement accuracy of the test and the simplicity of operation of the instrument.
(4) The instrument newly added network information transmission system, which can upload the test information and results in real time through the network cable, so as to facilitate remote monitoring of the test process and results.
(5) The instrument is equipped with a printing function. After the test, the test results and test conditions can be printed.
Based on the above characteristics, this new penetration meter designed by our company provides a computer automatic asphalt test instrument with high precision, good stability and reliable performance for highway, municipal administration, construction, petroleum and other fields in China.
Technical index of LZRD-7 high and low temperature asphalt penetration tester
(1) Displacement graduation: 0.01mm
(2) Displacement range: 0-50mm
(3) Indication error:≤ 0.03mm
(4) Needle and connecting rod: 50± 0.05g
(5) Weight: 50 0.05g can be composed of 100 0.05g to meet the test requirements.
(6) Temperature control accuracy:± 0.01℃
(7) Power supply: 220/50Hz
(8) Heating power: 270W
(9) Refrigeration power: 72W
(10) Water pump power: 12V4.8W
(11) Sample dish: copper cylindrical flat bottom, size: Φ 55mm*h35mm (when penetration is less than 200)
(12) Glass dish: capacity not less than 1L, depth not less than 80mm, not too large
Sample dish. A triangular support is provided to ensure the stability of the sample dish.
(13) Working platform: with adjustment level mechanism.- Name(chinese)
